Resistant To High Pressure, High Temperature, And Wear, With Strong Flexibility—Widely Applied In Coal, Petrochemicals, Metallurgy, Mining, Construction, Electricity, And More.
Construction:
Tube:Black,smooth,NR,SBR rubber compound.
Reinforcement:Multi plies High strength synthetic fibre and helix steel wire
Cover:Black,smooth,cloth impression,SBR rubber compound
Rubber Suction Hoseis a versatile hose with steel wire and textile reinforce. This hose is suitable for medium and heavy duty discharge apps where durability and longevity are of benefit.
Application:
Hardwall hose designed for suction and discharge of water,and non-corrosive fluids used in construction sitesand light duty industrial applications.Ideal high pressure water discharge hose for rugged, tough operating conditions
Temperature: -30ºC(-22ºF)to+80ºC(+176ºF)
Characteristics:
weathering and ozone resistant.
Anti-aging cover compound
Flexible and light weight
WATER SUCTION HOSE 150 PSI | ||||||||||
Item Code | I.D | O.D | W.P | B.P | Vacuum | L | ||||
inch | mm | mm | bar | psi | bar | psi | bar | m | ft | |
WSDH-019 | 3/4" | 19.1 | 30 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
WSDH-025 | 1" | 25.4 | 36 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
WSDH-032 | 1-1/4" | 31.8 | 44 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
WSDH-038 | 1-1/2" | 38.1 | 51 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
WSDH-050 | 2" | 50.8 | 64 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
WSDH-063 | 2-1/2" | 63.5 | 77 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
WSDH-076 | 3" | 76.2 | 90 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
WSDH-089 | 3-1/2" | 88.9 | 104 | 10 | 150 | 30 | 450 | 0.8 | 60 | 200 |
WSDH-102 | 4" | 101.6 | 118 | 10 | 150 | 30 | 450 | 0.8 | 30 | 200 |
WSDH-127 | 5" | 127 | 145 | 10 | 150 | 30 | 450 | 0.8 | 30 | 100 |
WSDH-152 | 6" | 152.4 | 170 | 10 | 150 | 30 | 450 | 0.8 | 30 | 100 |
WSDH-203 | 8" | 203.2 | 224 | 10 | 150 | 30 | 450 | 0.8 | 30 | 100 |
WSDH-276 | 10" | 254 | 276 | 10 | 150 | 30 | 450 | 0.8 | 12 | 40 |
WSDH-326 | 12" | 304 | 326 | 10 | 150 | 30 | 450 | 0.8 | 12 | 40 |
WSDH-378 | 14" | 350 | 378 | 10 | 150 | 30 | 450 | 0.8 | 12 | 40 |
WATER SUCTION HOSE 300 PSI | ||||||||||
Item Code | I.D | O.D | W.P | B.P | Vacuum | L | ||||
inch | mm | mm | bar | psi | bar | psi | bar | m | ft | |
WSH2-019 | 3/4" | 19.1 | 31 | 17 | 250 | 51 | 750 | 0.8 | 60 | 200 |
WSH2-025 | 1" | 25.4 | 38 | 17 | 250 | 51 | 750 | 0.8 | 60 | 200 |
WSH2-032 | 1-1/4" | 31.8 | 47 | 17 | 250 | 51 | 750 | 0.8 | 60 | 200 |
WSH2-038 | 1-1/2" | 38.1 | 53 | 17 | 250 | 51 | 750 | 0.8 | 60 | 200 |
WSH2-050 | 2" | 50.8 | 67 | 17 | 250 | 51 | 750 | 0.8 | 60 | 200 |
WSH2-063 | 2-1/2" | 63.5 | 82 | 17 | 250 | 51 | 750 | 0.8 | 60 | 200 |
WSH2-076 | 3" | 76.2 | 94 | 17 | 250 | 51 | 750 | 0.8 | 60 | 200 |
WSH2-089 | 3-1/2" | 88.9 | 110 | 17 | 250 | 51 | 750 | 0.8 | 60 | 200 |
WSH2-102 | 4" | 101.6 | 122 | 17 | 250 | 51 | 750 | 0.8 | 60 | 200 |
WSH2-127 | 5" | 127 | 150 | 17 | 250 | 51 | 750 | 0.8 | 30 | 100 |
WSH2-152 | 6" | 152.4 | 176 | 17 | 250 | 51 | 750 | 0.8 | 30 | 100 |
WSH2-203 | 8" | 203.2 | 232 | 17 | 250 | 51 | 750 | 0.8 | 12 | 40 |
WSH2-254 | 10" | 254 | 290 | 17 | 250 | 51 | 750 | 0.8 | 12 | 40 |
WSH2-304 | 12" | 304 | 340 | 17 | 250 | 51 | 750 | 0.8 | 12 | 40 |
