PP Folding Hose

Superior Quality for Multi-Industry Applications

Resistant To High Pressure, High Temperature, And Wear, With Strong Flexibility—Widely Applied In Coal, Petrochemicals, Metallurgy, Mining, Construction, Electricity, And More.

Duct&Vacuum Hose

Duct&Vacuum Hose

PP Folding Hose

Application

Drainage and transportation

Gas suction

Smoke suction

Ventilation and dust collection

Add To Cart

Inquiry

Product Description
Inquiry

Industry Hose

PP folding hose for drainage and ventilation

Characteristic

Soft and gentle texture

Flexible expansion and bending

Arbitrary shaping

Good airtightness

Good tensile strength

Structure

Color: White

Temperature: -20 ℃/+70 ℃

Short term temperature resistance+80 ℃

Hose wall: PP polypropylene

Reinforcement: Spiral steel wire

Part Number	Inter Diameter	Outside Dinameter	Wall Thickness	Working pressure	Burst pressure	Bending radius	Coil Lenghth
	mm	mm	mm	Bar	Bar	mm	m
025	25	32	0.6	0.70	0.34	35	10
032	32	38	06	0.65	0.32	42	10
038	38	46	0.6	0.58	0.30	50	10
051	51	58	0.6	0.43	0.24	65	10
063	63	73	0.6	0.35	0.18	80	10
076	76	85	0.6	0.30	0.13	93	10
090	90	100	0.6	0.25	0.10	110	10
102	102	112	0.6	0.23	0.08	122	10
127	127	137	0.6	0.18	0.06	150	10
152	152	162	0.6	0.16	0.05	178	10
203	203	213	0.6	0.12	0.02	233	10
