Resistant To High Pressure, High Temperature, And Wear, With Strong Flexibility—Widely Applied In Coal, Petrochemicals, Metallurgy, Mining, Construction, Electricity, And More.
Construction:
Tube: Synthetic rubber EPDM
Reinforcement: high tensile wire braiding
Cover:Red or blue, pin pricked smooth (wrapped finish) ,EPDM rubber
Application:
The steam hose is used for the saturated steam in chemical industry, petroleum industry, shipbuilding industry
Steam hose saturated and overheat steam. Used in the chemical and petrol, industrial clean, ship building, lumber and pulp process.
Prduct Name：EPDM Steam Hose
Working Pressure;150/250psi
Size&Colour：Red colour and multiple sizes
Temperatur：Up to 220°C（+446°F)
Characteristics:
1.Excellent resistance to high temperature
2.Weathering and ozoen resistance
3.High abrasion resistant cover
4.Anti aging,long service life
| Item code | I.D | O.D | W.P | B.P | Bend R | Wt | |||
| mm | inch | mm | bar | psi | bar | psi | mm | kg/m | |
| 010 | 10 | 3/8'' | 21 | 17 | 250 | 170 | 2500 | 50 | 0.45 |
| 012 | 12 | 1/2'' | 25 | 17 | 250 | 170 | 2500 | 60 | 0.53 |
| 016 | 16 | 5/8'' | 28 | 17 | 250 | 170 | 2500 | 70 | 0.6 |
| 019 | 19 | 3/4'' | 32 | 17 | 250 | 170 | 2500 | 80 | 0.68 |
| 025 | 25 | 1'' | 39 | 17 | 250 | 170 | 2500 | 110 | 0.9 |
| 032 | 32 | 1 1/4'' | 46 | 17 | 250 | 170 | 2500 | 150 | 1.3 |
| 038 | 38 | 1 1/2'' | 54 | 17 | 250 | 170 | 2500 | 180 | 1.6 |
| 051 | 51 | 2'' | 67 | 17 | 250 | 170 | 2500 | 245 | 2.2 |
| 064 | 64 | 2 1/2'' | 83 | 17 | 250 | 170 | 2500 | 300 | 3.8 |
| 076 | 76 | 3'' | 95 | 17 | 250 | 170 | 2500 | 400 | 4.6 |
| 089 | 89 | 3 1/2'' | 110 | 17 | 250 | 170 | 2500 | 500 | 5.2 |
| 102 | 102 | 4'' | 124 | 17 | 250 | 170 | 2500 | 600 | 6.5 |
