High Temperature Resistant Steam Hose

Superior Quality for Multi-Industry Applications

Resistant To High Pressure, High Temperature, And Wear, With Strong Flexibility—Widely Applied In Coal, Petrochemicals, Metallurgy, Mining, Construction, Electricity, And More.

Steam Hose

Steam Hose

High Temperature Resistant Steam Hose

Brief introduction of steam hose
Steam hose is manufactured by special rubber with good heat resistance and copper wire braid reinforced layer. It is suitable for continuous conveying saturated steam and superheated steam below the temperature of 150°C or intermittent conveying below the temperature of 160°C.
There are different kinds of steam hoses, such as fabric reinforced steam hose, steel wire braided steam hose, PTFE steam hose, iron steam hose and so on. High temperature resistant steam hose is one common kind of steam hose. The inside and outside layers of hose are made by high quality heat resistance of synthetic tube and the hose body has the characteristics of soft, lightweight, flexible, and high heat resistance.

Add To Cart

Inquiry

Product Description
Inquiry

Industry Hose

It is used for the conveyance of 165 °C ~ 220 °C saturated steam or superheated water, suitable for steam cleaning, steam hammer, vulcanizing machines, injection molding machines and hot pressing equipment.

Purposes: It is used for the conveyance of 165 °C ~ 220 °C saturated steam or superheated water, suitable for steam cleaning, steam hammer, vulcanizing machines, injection molding machines and hot pressing equipment.

Features:
Durable, long service life.
High temperature resistance, corrosion resistance, high pressure resistance.
Strong anti-destructive ability.
Light weight, flexible and sturdy.

Applications of steam hose
Our factory gives you steam hose to handle efficiently and safely no matter dry or wet, saturated or superheated. We stock a full range of steam hoses which are designed for the safe transfer of hot water and steam for processing products and cleaning equipment. They are used in numerous industries, such as refineries, food plants, shipyards, chemical plants, and for industrial cleaning, etc.

The specifications of steam hose

Item code	I.D		O.D	W.P		B.P		Bend R	Wt
Item code	mm	inch	mm	bar	psi	bar	psi	mm	kg/m
010	10	3/8''	21	17	250	170	2500	50	0.45
012	12	1/2''	25	17	250	170	2500	60	0.53
016	16	5/8''	28	17	250	170	2500	70	0.6
019	19	3/4''	32	17	250	170	2500	80	0.68
025	25	1''	39	17	250	170	2500	110	0.9
032	32	1 1/4''	46	17	250	170	2500	150	1.3
038	38	1 1/2''	54	17	250	170	2500	180	1.6
051	51	2''	67	17	250	170	2500	245	2.2
064	64	2 1/2''	83	17	250	170	2500	300	3.8
076	76	3''	95	17	250	170	2500	400	4.6
089	89	3 1/2''	110	17	250	170	2500	500	5.2
102	102	4''	124	17	250	170	2500	600	6.5
