Resistant To High Pressure, High Temperature, And Wear, With Strong Flexibility—Widely Applied In Coal, Petrochemicals, Metallurgy, Mining, Construction, Electricity, And More.
Construction:
Tube: Black EPDM
Reinforce: Multiple plies of polyester tire cord with wire helix
Cover: Black heat resistant EPDM rubber
Application:
Flexible and light weight hot air blower hose is to transfer hot air to tanks on dry bulk material trucks.
Hot air blower hose is a special hose for the bulk transport / tank truck industry only. The hose is generally made from high grade rubber to resist high temp. EPDM rubber is not suitable to transfer gasoline or oil. So it cannot serves in the petroleum transport / tank truck industry.
Temperature:
-30°F (-35°C) to +300°F (+149°C)
up to 325°F (+177°C) on an intermittent basis.
Not for steam service
Characteristic:
EPDM tube and cover for high heat resistance.
Temperature range up to +177°C (intermittent)
Excellent flexibility, exceleent anti aging.
All sizes are full vacuum
Code | ID | OD | W.P | B.P | Max.L | ||||
Inch | mm | mm | bar | psi | bar | psi | m | ft | |
038 | 1-1/2" | 38 | 50 | 10 | 150 | 30 | 450 | 61 | 200 |
050 | 2" | 50.8 | 64 | 10 | 150 | 30 | 450 | 61 | 200 |
064 | 2-1/2" | 64 | 76 | 10 | 150 | 30 | 450 | 61 | 200 |
076 | 3" | 76.2 | 91 | 10 | 150 | 30 | 450 | 61 | 200 |
089 | 3.5" | 89 | 104 | 7 | 100 | 21 | 300 | 61 | 200 |
102 | 4" | 102 | 120 | 5 | 75 | 15 | 225 | 61 | 200 |
127 | 5" | 127 | 144 | 5 | 75 | 15 | 225 | 61 | 200 |
152 | 6" | 152 | 170 | 5 | 75 | 15 | 225 | 30.5 | 100 |
