TPU Layflat Hose

Water Well Rising Hose

Water well rising hose is made from extruded thermoplastic polyether based polyurethane (TPU) with excellent wear & tear properties. The reinforcement is made from circular woven filament polyester yarn. The “extrusion through the weave” production method gives a very strong bonding between cover and lining as well as firmly encapsulating the woven polyester.

Industry Hose

Water Well Rising Hose

Description:

Water well rising hose is made from extruded thermoplastic polyether based polyurethane (TPU) with excellent wear & tear properties. The reinforcement is made from circular woven filament polyester yarn. The “extrusion through the weave” production method gives a very strong bonding between cover and lining as well as firmly encapsulating the woven polyester.

Applications:

  • Water Utility

  • Water Well

 Features:

  • A simpler, safer and more efficient way to install Submersible pumps. Offering greater cost savings and superior hydraulic performance advantages over Poly Pipe / PVC Pipe, Fiber Glass and Steel Riser Pipes.

  • Superior abrasion resistance

  • Extremely hardwearing and durable for long service life

  • Resistance to oil, fuel and a wide range of chemicals (see resistance table in technical appendix)

  • Resistance to weathering and ozone

  • Flexible, lightweight and good handling

  • Excellent cold flexibility




ID

ID

Thickness

Working pressure

Bursting pressure


Inch

mm

mm

PSl/bar

 PSl/bar

PU100

1

26+1.0

2.1

425/30

920/65

PU150

1.5

39+1.5

2.4

425/30

920/65

PU200

2

52+1.5

2.8

425/30

920/65

PU250

2.5

65+1.5

3.0

425/30

920/65

PU300

3

77+2.0

3.2

390/27

870/60

PU400

4

104+2.0

3.5

380/26

870/60

PU500

5

128+2.0

3.8

 360/25

 870/60

PU600

6

155+2.5

3.9

360/25

 870/60

PU800

8

204+3.0

4.5

 290/20

700/48
