Nitrile Fuel Discharge Hose

Superior Quality for Multi-Industry Applications

Resistant To High Pressure, High Temperature, And Wear, With Strong Flexibility—Widely Applied In Coal, Petrochemicals, Metallurgy, Mining, Construction, Electricity, And More.

Oil Hose

Oil Hose

Nitrile Fuel Discharge Hose

Construction:

Tube: Black,smooth,Nitrile.
Reinforcement: Multi plies high strength synthetic fabric
Cover: Black, wrapped surface,weather and ozone resistant,synthetic rubber

Application:

Softwall hose Designed for the discharge of petroleum based products,diesel,lubricants,fuel,with aromatic content up to 50%.

Add To Cart

Inquiry

Product Description
Inquiry

Industry Hose

Fuel Discharge Hoseis also called rubber fuel oil hose, flexible reinforced oil hose ,fuel oil discharge hose. It is a type of flexible hose for discharge and delivery of oil with aromatic content. Compared with water rubber hose, the oil rubber hose has inserted copper wire. While it’s to eliminate static by grounding. The inner and outer rubber material has excellent oil, abrasion and wear resistance performance. Additional, it has up to 50% aromatic content resistant performance for heavy duty applications.

Temperature: -32°C(-90°F) to +82°C(+180°F)

Characteristics:

Weather and abrasion resistant cover
Flexible and less distortion
For aromatic content up to 50%

NITRILE FUEL DISCHARGE HOSE 150 PSI
Item code	I.D		O.D	W.P		B.P		L
	I.D		O.D	W.P		B.P		L
	inch	mm	mm	bar	psi	bar	psi	m	ft
ODH012	1/2	12.7	21	10	150	30	450	61	200
ODH016	5/8	15.9	25	10	150	30	450	61	200
ODH019	3/4	19.1	29	10	150	30	450	61	200
ODH022	7/8	22.2	31	10	150	30	450	61	200
ODH025	1	25.4	35	10	150	30	450	61	200
ODH032	1-1/4	31.8	42	10	150	30	450	61	200
ODH038	1-1/2	38.1	51	10	150	30	450	61	200
ODH050	2	50.8	64	10	150	30	450	61	200
ODH064	2-1/2	63.5	76	10	150	30	450	61	200
ODH076	3	76.2	89	10	150	30	450	61	200
ODH089	3-1/2	88.9	103	10	150	30	450	61	200
ODH100	4	101.6	116	10	150	30	450	61	200
ODH125	5	127	142	10	150	30	450	30.5	100
ODH150	6	152.4	167	10	150	30	450	30.5	100
ODH200	8	203.2	223	10	150	30	450	30.5	100
NITRILE FUEL DISCHARGE HOSE 300 PSI
Item Code	I.D		O.D	W.P		B.P		L
	I.D		O.D	W.P		B.P		L
	inch	mm	mm	bar	psi	bar	psi	m	ft
ODH3-012	1/2	12.7	22	20	300	60	900	61	200
ODH3-016	5/8	15.9	26	20	300	60	900	61	20
