Resistant To High Pressure, High Temperature, And Wear, With Strong Flexibility—Widely Applied In Coal, Petrochemicals, Metallurgy, Mining, Construction, Electricity, And More.
Construction:
Tube: Black,smooth,Nitrile rubber
Reinforcement: High strength synthetic fabric and helix wire,with anti-static wire
Cover:Black or Red,smooth or corrugated ,oil,fuel,and weathering resistant synthetic rubber
Application:
Hardwall hose designed for suction and delivery of a wide range of petroleum fuel with aromatic content up to 50% for tank trucks.
Tank Truck hoseis designed for tank tanker, rail tanker, in-plant and oilfield loading.
Temperature: -32°C (-90°F) to +82°C (+180°F)
Characteristics:
1.Weather and abrasion resistant cover
2.Corrugated cover available,more flexible
3.Light weight,easy to handle
4.Designed for aromatic content up to 50%
| Item Code | I.D | O.D | W.P | B.P | L | ||||
| inch | mm | mm | bar | psi | bar | psi | m | ft | |
| 050 | 2" | 50.8 | 63 | 10 | 150 | 30 | 450 | 61 | 200 |
| 064 | 2-1/2" | 63.5 | 76 | 10 | 150 | 30 | 450 | 61 | 200 |
| 076 | 3" | 76.2 | 89 | 10 | 150 | 30 | 450 | 61 | 200 |
| 089 | 3-1/2" | 88.9 | 103 | 10 | 150 | 30 | 450 | 61 | 200 |
| 100 | 4" | 101.6 | 120 | 10 | 150 | 30 | 450 | 61 | 200 |
| 125 | 5" | 127 | 147 | 10 | 150 | 30 | 450 | 30.5 | 100 |
| 150 | 6" | 152.4 | 172 | 10 | 150 | 30 | 450 | 30.5 | 100 |
